MS3126E10-6P

Manufacturer	Amphenol Corporation
Description	Conn MIL-C-26482 Circular PIN 6 POS Crimp ST Cable Mount 6 Terminal 1 Port MIL-C-26482 Series 1 Connector, Crimp Contacts CONN PLUG 6POS STRAIGHT W/PINS Circular MIL Spec Connector 6P STRAIGHT PIN PLUG SZ 10 MIL-C-26482 I CONNECTOR, CIRCULAR, SIZE 10, 6WAY
Category	连接器解决方案圆形连接器标准圆形连接器

对参数有疑问？问 AI 助手

商业参数

其他名称

MS3126E10-6P-ND

标准包装数量

Bulk

合规参数

RoHS	Contains lead / RoHS non-compliant	MIL类型	MIL-DTL-26482
海关税号	85369010	认证机构	:MIL-C-26482 Series I

电气参数

额定电压

600VAC

最大额定电流

7.5A

机械参数

重量	0.001	包装方式	Bulk
外壳尺寸	10	方向	N (Normal)
外壳样式	In-Line	端接方式	Crimp
重量（g）	18.50000	安装类型	Cable Mount
外壳镀层	Olive Drab Chromate over Cadmium	连接器类型	Plug, Male Pins
接触镀层	Gold	紧固类型	Bayonet Lock
安装样式	Wire	外壳材料（壳体）	Aluminum Alloy
插入角度	10-6	本体材料	:Aluminium
触头材料	Copper Alloy	端接样式	Crimp
第一触头极性	Pin (Male)	配接方向	Bayonet
触点数	6	接触件端接	:Crimp
位数	6	外壳尺寸-插件	10-6
外壳材料及表面处理	Aluminum, Olive Drab Cadmium Plated	第一连接器安装类型	:Cable

产品信息

类型	MIL-C-26482 Circular	连接器性别	PL
系列	MS	产品子类型	Plugs

环境参数

防护等级

Environment Resistant

工作温度

-55°C ~ 125°C

Documents & Media

PDF Document

PT.pdf

PDF Document

MIL-C-26482, Series 1

PDF Document

inhouse_Amphenol_DTL-5015_connectors-183710.pdf

PDF Document

14136.pdf
