LT3518EFE#PBF
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 95 | Standard Package Name | TSSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Rad Hardened | No | ||
Electrical
| Dimming | :PWM | Frequency | 250kHz ~ 2.5MHz |
| Display Type | :LED | Voltage Rating | 12 V, 15 V, 18 V, 24 V, 3.3 V, 5 V, 9 V |
| Current - Output | 10000 mA | Current - Supply | 10 mA |
| Voltage - Supply | 3 V ~ 30 V | Number of Outputs | 1 |
| Frequency - Switching | :2.5MHz | Voltage - Input (Min) | :3V |
| Voltage - Supply (Min) | 3 V | Constant Current Load - Max | Yes |
| Common Mode Transient Immunity (Min) | Extended | Voltage - Continuous Operating (Max) (MCOV) | :30V |
Mechanical
| Width | 4.5mm | Height | 0.95mm |
| Length | 5.1mm | Weight | 0.0002 |
| Packaging | Tube | Case Color | :TSSOP |
| Lead Style | Gull-wing | Termination | :SMD |
| Mounting Type | Surface Mount | Number of Pins | :16 |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) Exposed pad | Package Cooled | TSSOP EP |
| Material Finish | :MSL 1 - Unlimited | Package Quantity | TSSOP EP |
| Size / Dimension | 5.1 x 4.5 x 0.95mm | Number of Positions | 16 |
| Supplier Device Package | 16-TSSOP-EP | ||
Product Info
| Type | White LED | DELETED | Compliant |
| Topology | PWM, Step-Down (Buck), Step-Up (Boost) | Base Unit | :3518 |
| Number of Segments | 3 | Internal Connection | No |
| Application Specifics | :Automotive Lighting, Display Backlighting | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | Operating Temperature - Junction | 125C |
