LTC2256IUJ-14#PBF
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | LTC2256IUJ14PBF | Standard Package | 61 |
| Standard Package Name | QFN | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423190 | ||
Electrical
| Interface | Parallel|Serial (SPI)|LVDS | Input Type | Voltage |
| Resolution | 14bit | Input Signal | Differential |
| INL/DNL (LSB) | ±2.5LSB | Converter Type | General Purpose |
| Data Interface | Parallel, Serial, SPI | Number of Bits | 14 |
| Voltage Rating | 1Vp-p/2Vp-p | Current - Output | :19.5mA |
| Voltage - Supply | :Single | Resolution (Bits) | :14bit |
| Voltage Reference | Internal|External | Sampling Frequency | 25Msps |
| Number of ADCs / DACs | 1 | Voltage Supply Source | Single |
| Power Dissipation (Max) | 126 | Differential Nonlinearity | ±0.8LSB |
| Sampling Rate (Per Second) | 25M | Differential - Input:Output | Yes |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 6 | Weight | 0 |
| Packaging | Tube | Lead Style | No Lead |
| Mounting Type | Surface Mount | Number of Pins | :40 |
| Package / Case | 40-WFQFN Exposed Pad | Length - Overall | 6 |
| Package Quantity | QFN EP | Number of Positions | 40 |
| Shell Size - Insert | 0.75(Max) | Supplier Device Package | 40-QFN (6x6) |
Product Info
| Architecture | Pipelined | Printed Circuit Board | 40 |
| Number of A/D Converters | 1 | Number of Inputs and Type | 1 Differential |
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
Documents & Media
PDF Document
Online Document
Sourcing & traceability
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
