LTC2400CS8#PBF
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | LTC2400CS8PBF | Standard Package | 100 |
| Standard Package Name | SOIC | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
Electrical
| Interface | Serial (2-Wire, 3-Wire, SPI, Micr... | Input Type | Voltage |
| Resolution | 24bit | Input Signal | Single-Ended |
| INL/DNL (LSB) | 15ppm of Vref | Converter Type | Temperature Measurement |
| Data Interface | MICROWIRE™, Serial, SPI™ | Input Polarity | Unipolar |
| Number of Bits | 24 | Voltage Rating | 6.188V |
| Current - Output | :200µA | Voltage - Supply | 3.3 V, 5 V |
| Resolution (Bits) | :24bit | Voltage Reference | External |
| Number of Channels | :1 | Sampling Frequency | 7.5sps |
| Number of ADCs / DACs | 1 | Voltage Supply Source | Single |
| Voltage Supply - Internal | :2.7V to 5.5V | Sampling Rate (Per Second) | 7.5 |
| Differential - Input:Output | No | Common Mode Transient Immunity (Min) | Commercial |
Mechanical
| Width | 3.99mm | Height | 1.48mm |
| Length | 5mm | Weight | 0.0001 |
| Packaging | Tube | Lead Style | Gull-wing |
| Termination | :SMD | Mounting Type | Surface Mount |
| Number of Pins | :8 | Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Package Cooled | SOIC N | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 5(Max) | Package Quantity | SOIC N |
| Size / Dimension | 5 x 3.99 x 1.48mm | Number of Positions | 8 |
| Shell Size - Insert | 1.5(Max) | Supplier Device Package | 8-SOIC |
Product Info
| Spg | 5 | Type | A/D converter |
| Architecture | Delta-Sigma | Number of Units | 1 |
| Printed Circuit Board | 8 | Number of A/D Converters | 1 |
| Number of Inputs and Type | 1 Single-Ended, Unipolar | ||
Environmental
| Operating Temperature | 0°C ~ 70°C | ||
Documents & Media
Online Document
PDF Document
Similar Parts
Sourcing & traceability
- Datasheet
- LTC2400
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
