LTM9010IY-14#PBF
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | LTM9010IY14PBF | Standard Package | 210 |
| Standard Package Name | BGA | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
Electrical
| Interface | Serial|LVDS | Input Type | Voltage |
| Resolution | 14bit | Input Signal | Differential |
| INL/DNL (LSB) | ±3.25LSB | Converter Type | General Purpose |
| Data Interface | Serial LVDS | Input Polarity | Bipolar |
| Number of Bits | 14 | Voltage Rating | 1Vp-p/2Vp-p |
| Current - Output | :476mA | Voltage - Supply | :1.7V to 1.9V |
| Resolution (Bits) | :14bit | Voltage Reference | Internal|External |
| Number of Channels | :8 | Sampling Frequency | 105Msps |
| Number of ADCs / DACs | 8 | Voltage Supply Source | Single |
| Power Dissipation (Max) | 1105 | Differential Nonlinearity | ±0.8LSB |
| Voltage Supply - Internal | :1.7V to 1.9V | Sampling Rate (Per Second) | 105M |
| Differential - Input:Output | Yes | ||
Mechanical
| Width | 9 | Weight | 0.0002 |
| Packaging | Tray | Lead Style | Ball |
| Mounting Type | Surface Mount | Number of Pins | :140 |
| Package / Case | 140-BFBGA | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 11.25 | Package Quantity | BGA |
| Number of Positions | 140 | Shell Size - Insert | 2.32 |
| Supplier Device Package | 140-BGA (11.25x9) | ||
Product Info
| Printed Circuit Board | 140 | Number of A/D Converters | 8 |
| Number of Inputs and Type | 8 Differential; 8 Single-Ended | ||
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
Documents & Media
Online Document
Sourcing & traceability
- Datasheet
- LTM9011/10/09-14
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
