ADF4106BRU-REEL7
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADF4106BRU-REEL7CT | Standard Package | Tape & Reel |
Compliance
| RoHS | Not Compliant | ||
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Frequency | Up to 325 |
| Frequency - Max | 6000 MHz | Frequency Range | Up to 325 |
| Current - Output | 13 mA | Voltage - Supply | 3 V |
| Divider/Multiplier | Yes/No | Number of Elements | 1 |
| Ratio - Input:Output | 2:1 | Voltage - Input (Min) | 3.3 |
| Current - Supply (Max) | 13 | Voltage - Supply (Min) | 3 |
| Minimum Input Frequency | 20 MHz | DC Voltage - Input (Min) | 20 |
| Differential - Input:Output | Yes/No | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 4.4 | Packaging | Tape and Reel |
| Mounting Type | Surface Mount | Conductor Type | Gull-wing |
| Mounting Style | SMD/SMT | Number of Pins | 16 |
| Package / Case | 16TSSOP | Package Cooled | TSSOP |
| Length - Overall | 5 | Packages Included | TSSOP |
| Shell Size - Insert | 1.05(Max) | Supplier Device Package | 16-TSSOP |
Product Info
| Type | PLL Frequency Synthesizer | Series | ADF4106 |
| Number of Circuits | 1 | RF Family/Standard | ADF4106 |
| Printed Circuit Board | 16 | Assembly Configuration | Surface Mount |
Environmental
| Operating Temperature | -40 to 85 °C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- ADF4106.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
