ADF4106BRU
| Manufacturer | |
| Description | PLL Frequency Synthesizer Single Up to 325MHz 16-Pin TSSOP IC PLL FREQ SYNTHESIZER 16-TSSOP Phase Locked Loops - PLL Freq Synthesizer |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 96 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | RoHS non-compliant | EU RoHS | Not Compliant |
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Voltage Rating | 2.7 |
| Frequency - Max | 6000 MHz | Frequency Range | Up to 325 |
| Current - Output | 13 mA | Current - Supply | 13 |
| Voltage - Supply | 3 V | Divider/Multiplier | Yes/No |
| Number of Elements | 1 | Ratio - Input:Output | 2:1 |
| Voltage - Supply (Min) | 3.3 | Minimum Input Frequency | 20 MHz |
| Differential - Input:Output | Yes/No | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 16TSSOP | Package Quantity | TSSOP |
| Number of Positions | 16 | Supplier Device Package | 16-TSSOP |
Product Info
| Type | PLL Frequency Synthesizer | Series | ADF4106 |
| Number of Circuits | 1 | RF Family/Standard | ADF4106 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
