ADF4113BRUZ-REEL
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADF4113BRUZ-REELCT | Standard Package | Tape & Reel |
| Factory Pack Quantity | 2500 | Standard Package Name | TSSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Frequency - Max | 4000 MHz |
| Current - Output | 8.5 mA | Current - Supply | 8.5 mA |
| Voltage - Supply | 3|5 V | Divider/Multiplier | Yes/No |
| Number of Elements | 1 | Ratio - Input:Output | 2:1 |
| Voltage - Supply (Min) | 2.7 V | Minimum Input Frequency | 5 MHz |
| Differential - Input:Output | Yes/No | ||
Mechanical
| Width | 4.4 | Height | 1.05 mm (Max) |
| Length | 5 mm | Packaging | Tape & Reel (TR) |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 16TSSOP |
| Package Cooled | TSSOP | Length - Overall | 5 |
| Package Quantity | TSSOP | Number of Positions | 16 |
| Shell Size - Insert | 1.05(Max) | Supplier Device Package | 16-TSSOP |
Product Info
| Type | PLL Frequency Synthesizer | Series | ADF4113 |
| Manufacturer | Analog Devices | Number of Circuits | 1 |
| RF Family/Standard | ADF4113 | Printed Circuit Board | 16 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- ADF4110_4111_4112_4113.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
