ADL5330ACPZ
| Category |
对参数有疑问？问 AI 助手
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85423300 |
Electrical
| Gain | :20dB | Noise | :14.7dB |
| Noise Figure | 14.7dB | Voltage Rating | 4.75 V |
| Frequency - Max | 3 GHz | Frequency - Min | :10MHz |
| Frequency Range | :10MHz to 3GHz | Current - Output | :215mA |
| Voltage - Supply | :4.75V | Number of Channels | 1 |
| Voltage - Supply (Min) | 5.25 V | Power Dissipation (Max) | :1.1W |
| Power (Typ) @ Conditions | 32 dB | ||
Mechanical
| Width | 4mm | Height | 0.83mm |
| Length | 4mm | Weight | 0.001 |
| Mounting Type | Surface Mount | -3db Bandwidth | 3000MHz |
| Number of Pins | :24 | Package / Case | :LFCSP |
| Package Cooled | LFCSP EP | Material Finish | :MSL 3 - 168 hours |
| Size / Dimension | 4 x 4 x 0.83mm | Number of Positions | 24 |
Product Info
| RF Type | :W-CDMA | Amplifier Type | Gain |
Environmental
| Operating Temperature | +85 °C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- ADL5330.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
