ADP1720ARMZ-3.3-R7
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADP1720ARMZ-3.3-R7CT | Standard Package | Tape & Reel |
| Factory Pack Quantity | 1000 | Standard Package Name | MSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Accuracy | ±2 % | Output Type | Fixed |
| Regulator Type | LDO | Voltage Rating | 4 V |
| Line Regulation | 0.15 % | Load Regulation | 0.01 % |
| Current - Output | 0.05 A | Voltage - Supply | 0.1@1mA|0.2@10mA|0.3@50mA V |
| Number of Outputs | 1 | Regulator Topology | Positive Fixed |
| Number of Regulators | 1 | Voltage - Input (Min) | 3.3V |
| Output Voltage Accuracy | �2 % | DC Voltage - Input (Min) | 4 V |
| Current - Quiescent (Max) | 0.025 mA | Common Mode Transient Immunity (Min) | Extended Industrial |
Mechanical
| Width | 3 | Height | 0.85 mm |
| Length | 3 mm | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8MSOP |
| Package Cooled | MSOP | Length - Overall | 3 |
| Package Quantity | MSOP | Number of Positions | 8 |
| Shell Size - Insert | 0.85 | Supplier Device Package | 8-MSOP |
Product Info
| Type | LDO | Series | ADP1720 |
| Features | Short Circuit Protection|Thermal ... | Polarity | Positive |
| Topology | LDO | Manufacturer | Analog Devices |
| Printed Circuit Board | 8 | ||
Environmental
| Operating Temperature | -40 to 125 °C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- ADP1720.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
