ADSP-BF537KBCZ-6AV
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | Blackfin | Other Names | ADSPBF537KBCZ6AV |
| Standard Package | Trays | Factory Pack Quantity | 189 |
| Standard Package Name | BGA | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Rad Hardened | No | ||
Electrical
| Speed | 600 MHz | RAM Size | 32 KB |
| Core Size | 16 b | Core Type | Blackfin |
| Frequency | :600MHz | Interface | CAN, SPI, SSP, TWI, UART |
| Clock Rate | 600 MIPS | Memory Size | 32 KB |
| Voltage - I/O | 3.30V | Number of Bits | :16 bit |
| Voltage - Core | 1.30V | Voltage Rating | 1.3 V, 2.5 V, 3.3 V |
| Clock Frequency | 600 MHz | Frequency - Max | 600MHz |
| Voltage - Supply | 1.3|2.5|3.3 V | Non-Volatile Memory | External |
| Program Memory Size | Not Required kB | Program Memory Type | ROMLess |
| Voltage - Supply (Min) | 0.8/2.25 V | ||
Mechanical
| Width | 12mm | Height | 1.21mm |
| Length | 12mm | Weight | 0.0001 |
| Packaging | Tray | Lead Style | Ball |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :182 | Package / Case | 182CSP-BGA |
| Package Cooled | CSP BGA | Material Finish | :MSL 3 - 168 hours |
| Package Quantity | CSP-BGA | Size / Dimension | 12 x 12 x 1.21mm |
| Number of Positions | 182 | Supplier Device Package | 182-CSPBGA (12x12) |
| Number of Cores/Bus Width | 16 Bit | ||
Product Info
| Type | Fixed Point | Format | Fixed Point |
| Series | ADSP-BF537 | On-Chip RAM | 132kB |
| Architecture | Modified Harvard | Programmable | No |
| Number Format | Fixed-Point | Other Specifications | 600 |
Environmental
| Operating Temperature | 0°C ~ 70°C | Operating Temperature - Junction | 70C |
Documents & Media
PDF Document
PDF Document
PDF Document
Similar Parts
Sourcing & traceability
- Datasheet
- ADSP-BF534_BF536_BF537.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
