ADUC7020BCPZ62I
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 490 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423190 | Rad Hardened | No |
| Approval Agency | No | ||
Electrical
| Speed | 44 MHz | Timer | 2 x 16 bit, 2 x 32 bit |
| RAM Size | 8 KB | Core Size | 16/32-Bit |
| Core Type | ARM7TDMI | Frequency | 44 MHz |
| Interface | I2C/SPI/UART | Clock Rate | 40 MHz |
| Resolution | 16bit | Memory Size | 8192 B |
| Number of I/O | 14 | Number of Bits | 12 |
| Voltage Rating | 2.7 → 3.6 V | Watchdog Timer | 1 |
| Clock Frequency | :44MHz | Data Converters | A/D 5x12b; D/A 4x12b |
| Frequency - Max | 44MHz | Number of DAC's | 4 |
| Oscillator Type | Internal | Serial Protocol | 1 |
| Voltage - Supply | 3.3 V | Resolution (Bits) | 12bit |
| Number of Channels | 0 | Program Memory Size | 62 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 5 |
| Voltage - Supply (Min) | 2.7 V | Frequency (Center/Band) | 16 bit, 32 bit |
| Power Dissipation (Max) | 120(Typ) mW | Number of Bits per Element | 12 |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 3.6 V | ||
Mechanical
| Width | 6mm | Height | 0.85mm |
| Length | 6mm | Weight | 0 |
| Packaging | Tray | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :40 | Package / Case | 40LFCSP EP |
| Package Cooled | LFCSP VQ | Material Finish | :- |
| Length - Overall | 6 | Package Quantity | LFCSP EP |
| Size / Dimension | 6 x 6 x 0.85mm | Number of Positions | 40 |
| Shell Size - Insert | 0.83 | Number of Cores/Bus Width | 16|32 Bit |
| Pulse Width Distortion (Max) | 6 x 16 bit | ||
Product Info
| SPI | 1 | USB | 0 |
| Series | ARM7 | Protocol | 2 |
| On-Chip RAM | 5-chx12-bit | Peripherals | PLA, PWM, PSM, Temp Sensor, WDT |
| Architecture | RISC | Connectivity | EBI/EMI, I²C, SPI, UART/USART |
| Programmable | Yes | Core Processor | ARM7® |
| Number of Timers | 4 | RF Family/Standard | ADuC7xxx |
| DigiKey Programmable | Yes | Printed Circuit Board | 40 |
Environmental
| Operating Temperature | -40 to 125 °C | Operating Temperature - Junction | 125C |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
