ADUC7061BCPZ32
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Approval Agency | No | ||
Electrical
| Speed | 10.24 MHz | RAM Size | 4 KB |
| Core Size | 16/32-Bit | Core Type | ARM7TDMI |
| Interface | I2C/SPI/UART | Clock Rate | 10.24 |
| Memory Size | :4KB | Number of I/O | 14 |
| Number of Bits | 24/24 | Voltage Rating | 2.375 |
| Watchdog Timer | 1 | Clock Frequency | :10MHz |
| Data Converters | A/D 5x24b, 8x24b, D/A 1x14b | Number of DAC's | :6 |
| Oscillator Type | Internal | Serial Protocol | 1 |
| Voltage - Supply | 2.5 V | Program Memory Size | 32 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 4/4 |
| Voltage - Supply (Min) | 2.625 | Voltage - Supply (Vcc/Vdd) | 2.375 V ~ 2.625 V |
Mechanical
| Weight | 0.299 | Packaging | Tube |
| Lead Style | No Lead | Number of Pins | :32 |
| Package / Case | 32LFCSP EP | Material Finish | :MSL 3 - 168 hours |
| Package Quantity | LFCSP EP | Number of Positions | 32 |
| Number of Cores/Bus Width | 16|32 Bit | ||
Product Info
| SPI | 1 | Protocol | 1 |
| On-Chip RAM | 2(4-chx24-bit) | Peripherals | POR, PWM, Temp Sensor, WDT |
| Architecture | RISC | Connectivity | I²C, SPI, UART/USART |
| Core Processor | ARM7® | Number of Timers | 4 |
| Controller Series | :ARM7 | RF Family/Standard | ADuC7xxx |
| DigiKey Programmable | Yes | ||
Environmental
| Operating Temperature | -40 to 125 °C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- ADuC7060_7061.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
