Business
| Other Names | ADUC845BSZ625 | Standard Package | Trays |
| Factory Pack Quantity | 96 | Standard Package Name | QFP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Approval Agency | No | ||
Electrical
| Speed | 12.85 MHz | RAM Size | 2.25 KB |
| Core Size | 8-Bit | Core Type | 8052 |
| Interface | I2C/SPI/UART | Clock Rate | 12 MHz |
| EEPROM Size | 4K x 8 | Memory Size | 2304 B |
| Number of I/O | 24 | Number of Bits | 24/24 |
| Voltage Rating | 4.75 | Watchdog Timer | 1 |
| Clock Frequency | :12.58MHz | Data Converters | A/D 10x24b; D/A 1x12b, 2x16b |
| Number of DAC's | 1 | Oscillator Type | Internal |
| Serial Protocol | 1 | Voltage - Supply | 5 V |
| Number of Channels | 10 | Program Memory Size | 62 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 10/10 |
| Voltage - Supply (Min) | 5.25 | Number of Bits per Element | 12 |
| Voltage - Supply (Vcc/Vdd) | 4.75 V ~ 5.25 V | ||
Mechanical
| Weight | 0.00001 | Packaging | Tray |
| Lead Style | Gull-wing | Termination | :SMD |
| Mounting Style | SMD/SMT | Number of Pins | :52 |
| Package / Case | 52MQFP | Material Finish | :MSL 3 - 168 hours |
| Package Quantity | MQFP | Number of Positions | 52 |
| Number of Cores/Bus Width | 8 Bit | ||
Product Info
| SPI | 1 | Series | ADUC845 |
| Protocol | 1 | Flash Size | :62KB |
| On-Chip RAM | 2(10-chx24-bit) | Peripherals | POR, PSM, PWM, Temp Sensor, WDT |
| Architecture | CISC | Connectivity | I²C, SPI, UART/USART |
| Core Processor | 8052 | Number of Timers | 3 |
| Controller Series | :ADuC8xx | RF Family/Standard | ADuC8xx |
| DigiKey Programmable | Yes | Number of A/D Converters | :10 |
Environmental
| Operating Temperature | -40 to 125 °C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- ADUC845_847_848.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
