Q22P1CXXW24E
| Manufacturer | |
| Description | LED Panel Mount Indicators INDICATOR 24V 22MM PROM WHITE 22mm prominent bright chrome bezel IP67 sealed WHITE 24V LED Indicator white 24 VDC, Q22P1CXXW24E, Apem |
| Category |
对参数有疑问？问 AI 助手
Business
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Current | 20 | Voltage | 24 VDC |
| Optic Size | 22 mm | Luminous Flux | 350 mcd |
| Viewing Angle | 100 deg | LED Forward Current | 20 mA |
| LED Forward Voltage | 24 V | Voltage - Protection Level (VP) (2416) | IP 67 |
Mechanical
| Light Color | white | Mounting Style | Panel |
| Optic Diameter | 18 | Termination Style | Blade Terminal 2.8 x 0.8 mm |
| Diameter - Outside | 22 | Illumination Color | White |
| Diameter - Outside, Non-Expanded | 25 x 52 mm | ||
Product Info
| Type | LED Indicator | Lens Type | Convex |
| Angle of Incidence (AOI) | 100 | ||
Environmental
| Operating Temperature | -40...+85 °C | Luminous Flux @ Current/Temperature | 350 mcd |
Documents & Media
PDF Document
