NLP40-76T366J
| Manufacturer | |
| Description | AC/DC Power Supply Triple-OUT 3.3V/12V/-12V 4.5A/3A/0.5A 50W 9-Pin AC/DC CONVERTER 3.3V +/-12V 40W |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Approval Agency | CE, CSA, VDE |
Electrical
| Frequency | 47 to 440 Hz | Efficiency | 75(Typ) % |
| Output Type | AC/DC三路Triple开关电源 | Power - Max | 50 W |
| Power (Watts) | 40W (50W Forced Air) | Voltage Range | 90-264 |
| Power - Output | 40 | Voltage Rating | 90 to 264 V |
| Current - Output | 4.5|3|0.5 A | Efficiency - Type | 75 |
| Number of Outputs | 3 | Voltage - Nominal | 110/220 |
| Voltage - Output 3 | -12V | Power (Watts) - Max | 40W (50W Forced Air) |
| Voltage - Isolation | 3kV (3000V) | Current Rating (Max) | 1.4(rms) A |
| Minimum Load Required | Yes | Voltage - Input (Min) | 3.3V |
Mechanical
| Size | 4.25*2.50*1.15 | Mounting Type | Chassis Mount |
| Size / Dimension | 4.25" L x 2.50" W x 1.15" H (108.0mm x 63.5mm x 29.2mm) | ||
Product Info
| Type | Switching | Features | Adjustable Output, Universal Input |
| Applications | ITE (Commercial) | ||
Environmental
| Operating Temperature | 0 to 70 °C | ||
