145802032002829+
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 478-5644-2 | Product Category | Board to Board & Mezzanine Connectors |
| Standard Package | 2,000 | Factory Pack Quantity | 2000 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 0.3 | Voltage - Input (Min) | 50VDC|50VAC |
Mechanical
| Depth | 1.75 | Pitch | 0.016" (0.40mm) |
| Height | 0.66 | Packaging | Reel |
| Termination | Solder | Mounting Type | Surface Mount |
| Connector Type | Plug, Outer Shroud Contacts | Contact Finish | Gold |
| Number of Rows | 2 | Contact Material | Copper Alloy |
| Housing Material | Plastic | Length - Overall | 5.76 |
| Height Above Board | 0.026" (0.65mm) | Number of Contacts | 32 |
| Number of Positions | 32 | Mated Stacking Heights | 0.8mm |
| Contact Finish Thickness | 3.9µin (0.10µm) | ||
Product Info
| Type | Board to Board | Gender | PL |
| Series | 5802 | Features | Board Guide, Solder Retention |
Documents & Media
Similar Parts
Sourcing & traceability
- Datasheet
- 5802 Series
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
