940-SP-3088R
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 5,000 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :CSA, UL | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | 150V | Contact Resistance | :10mohm |
| Dielectric Strength | :1000V | Current Rating (Max) | 1.5A |
| Insulation Resistance | :500Mohm | Connector - Voltage Input | :- |
Mechanical
| Color | Translucent - Clear | Depth | :7.9mm |
| Width | :11.7mm | Height | :22.5mm |
| Length | 0.885" (22.48mm) | Weight | 0.024 |
| Packaging | Bulk | Shielding | Unshielded |
| Cable Type | Round Cable, Solid or Stranded Wires | Wire Gauge | :26AWG |
| Termination | IDC | Connector Type | :RJ45 |
| Contact Finish | Gold | Plating - Body | :Gold |
| Contact Material | Phosphor Bronze | Housing Material | Polycarbonate (PC) |
| Color - Connectors | :Clear | Number of Contacts | :8 |
| Contact Termination | :Crimp | Number of Positions | :8 |
| Contact Finish Thickness | 50µin (1.27µm) | Material - Housing & Prism | :Polycarbonate |
Product Info
| Gender | :Plug | Series | :30 |
| Number of Ports | :1 | Number of Positions/Contacts | 8p8c (RJ45, Ethernet) |
Environmental
| Mating Cycles | :1000 | Operating Temperature | :125°C |
