3006P-1-203
| Manufacturer | |
| Description | Trimmer Resistors - Through Hole 20K 3/4 10% Sealed Multi Turn Res Cermet Trimmer 20K Ohm 10% 0.75W(3/4W) 15(Elec)Turn 2.36mm (20.57 X 4.83 X 6.35mm) Pin Thru-Hole Tube TRIMMER 20K OHM 0.75W PC PIN |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Trimmers | Product Category | Trimmer Resistors - Through Hole |
| Standard Package | 25 | Factory Pack Quantity | 100 |
Compliance
| RoHS | No | EU RoHS | Not Compliant |
Electrical
| Tolerance | 10 % | Resistance | 20 kOhms |
| Element Type | Cermet | Power (Watts) | 0.75W, 3/4W |
| Power - Rated | 750 mW (3/4 W) | Resistance (Ohms) | 20k |
Mechanical
| Depth | 4.83 | Taper | Linear |
| Height | 6.35 | Packaging | Tube |
| Mounting Type | Panel Mount | Shaft Diameter | 2.36 |
| Length - Overall | 20.57 | Size / Dimension | 4.83 mm W x 19.05 mm L |
| Termination Style | Radial | Resistive Material | Cermet |
Product Info
| Type | Trimming Potentiometer | Technology | Cermet |
| Product Type | Multi-Turn | Adjustment Type | Side Slot |
| Number of Turns | Multi Turn | ||
Environmental
| Operating Temperature | - 55 C to + 125 C | Temperature Coefficient | ±100ppm/°C |
Documents & Media
PDF Document
PDF Document
Similar Parts
H-83P
bourns
RETRO-FIT PANEL MOUNTS Customer Installed Panel Mount Unsealed RETRO FIT PANEL MNT HOLDER Potentiometer Tools & Hardware 3005/3006 ADAPTER PANEL MOUNT, POTENTIOMETER Adapter,Trimmer;Retro-FitMountingPanel;ThrdSz5/16In-32Unef Adapter; Body dim:22x9.53x9.53mm; dcutout:8mm Adapter for potentiometer 3005/3006, H-83P, Bourns
$15.0960
Details
Q23466
