70ADJ-2-FL0G
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Battery Contacts | Product Category | Battery Holders, Snaps & Contacts |
| Standard Package | Tape & Reel | Factory Pack Quantity | 500 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 3/Contact | Voltage - Input (Min) | 30VDC |
Mechanical
| Color | Black | Depth | 11 |
| Pitch | 4 mm | Height | 2.3 |
| Material | Copper Alloy | Packaging | Reel |
| Termination | Solder | Mounting Type | Surface Mount |
| Connector Type | Compression Contact, Female | Contact Finish | Gold Over Nickel |
| Mounting Style | SMD/SMT | Number of Rows | 1 |
| Contact Material | Copper Alloy | Housing Material | Thermoplastic |
| Length - Overall | 9 | Number of Contacts | 2 |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Type | Battery | Gender | F |
| Number of Ports | 1 | Battery Cell Size | 70AD |
| Number of Batteries Included | 2 | ||
Environmental
| Operating Temperature | 125 | ||
Documents & Media
Sourcing & traceability
- Datasheet
- 70ADF.pdf
