Business
| Other Names | ACX1183 | Standard Package | Bag |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85366910 | Rad Hardened | No |
Electrical
| Frequency | 0 to 18 GHz | Impedance | 50 Ohm |
| Frequency - Max | 18GHz | ||
Mechanical
| Depth | 11 mm | Length | 19 in. |
| Weight | 0.005 | Packaging | Bulk |
| Cable Type | :RG405 | Body Finish | Gold |
| Cable Group | RG-405 (.085" Semi Rigid) | Termination | Solder |
| Body Material | Brass | Housing Color | Gold |
| Mounting Type | Panel Mount | Angle of Throw | Straight |
| Connector Type | Jack, Female Socket | Contact Finish | Gold |
| Fastening Type | Threaded | Housing Finish | Gold |
| Mounting Style | Panel | Plating - Body | Gold |
| Connector Style | SMA | Connector Usage | Threaded |
| Contact Material | Beryllium Copper | Housing Material | Brass |
| Length - Overall | 19 mm | Primary Material | SMA |
| Shield Termination | Solder | Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Insulation Material | Polytetrafluoroethylene |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper |
| Supplier Device Package | Straight | ||
Product Info
| Type | SMA | Gender | RCP |
| Connection Type | Semi-Rigid Cable | Application Specifics | Commercial |
Environmental
| Ingress Protection | Weatherproof | Operating Temperature | -65°C ~ 165°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 132105.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
