Business
| Product | Connectors | Other Names | ACX1236 |
| Part # Aliases | 319-0179 99H5027 SMA6351B1-3GT50G-50 | Product Category | RF Connectors / Coaxial Connectors |
| Standard Package | Bag | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Frequency | 0 to 18 GHz | Impedance | 50 Ohm |
| Coupling Factor | Threaded | Frequency - Max | 12.4GHz |
Mechanical
| Length | 0.682 in. | Weight | 0.088890 oz |
| Packaging | Bulk | Body Finish | Gold |
| Orientation | Straight | Termination | Solder Pot |
| Body Material | Brass | Housing Color | Gold |
| Mounting Type | Panel Mount | Angle of Throw | Straight |
| Connector Type | Jack, Female Socket | Contact Finish | Gold |
| Fastening Type | Threaded | Housing Finish | Gold |
| Plating - Body | Gold | Connector Style | SMA |
| Connector Usage | Threaded | Contact Material | Beryllium Copper |
| Housing Material | Brass | Length - Overall | 17.3 |
| Primary Material | SMA | Termination Style | Solder Cup |
| Shield Termination | Solder | Contact Termination | Solder Cup |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Insulation Material | Polytetrafluoroethylene |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper |
| Supplier Device Package | Bulkhead | ||
Product Info
| Type | SMA | Gender | RCP |
| Features | Extended Insulation | Polarity | Standard |
| Connection Type | Coaxial Cable | RF Family/Standard | SMA |
| Application Specifics | Commercial | ||
Environmental
| Mating Cycles | 500 | Operating Temperature | -65°C ~ 165°C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 132137.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
