PX0411/10S/6065

Business

Product Category	Standard Circular Connector	Standard Package	25
Factory Pack Quantity	25

RoHS	Compliant	SVHC	:No SVHC (19-Dec-2012)
Tariff No	85366990	Approval Agency	ULRecognized/CSA/VDE
Material Flammability Rating	:UL94V-0

Weight	0.005	Material	:Nitrile
Packaging	Bulk	Wire Gauge	:24AWG
Orientation	Keyed	Shell Style	Receptacle
Size - Body	Ø19.1 x 46mm	Termination	Crimp
Contact Type	Crimp and Solder Cup	Body Material	polyamide
Mounting Type	Free Hanging (In-Line)	Angle of Throw	Straight
Cable Diameter	6-6.5mm	Connector Type	Receptacle for Female Contacts
Contact Finish	Gold	Fastening Type	Threaded
Mounting Style	Free Hanging	Shell Material	Plastic
Insertion Angle	:-	Locking Feature	threaded joint, external thread
Material - Body	:Nylon (Polyamide)	Contact Material	Copper Alloy
Housing Material	Polyamide	Package Quantity	25
Primary Material	Sealed	Connector - Cable	plug
Termination Style	Crimp / Solder	1st Contact Gender	Female
Mating Orientation	Threaded	Number of Contacts	10
Number of Positions	10	Shell Size - Insert	:-
Shell Material, Finish	Polyamide	Wire Gauge or Range - AWG	:28AWG
1st Connector Mounting Type	:Cable	Diameter - Outside, Non-Expanded	:7mm
