PXP7011/10S/CR/0911
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 708-1651 | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage Rating | 277 V, 600 V | Current Rating (Max) | 6 A, 10 A |
| Connector - Voltage Input | Female | ||
Mechanical
| Weight | 0.055 | Packaging | Bulk |
| Wire Gauge | 20-18 | Orientation | Keyed |
| Shell Style | Receptacle | Contact Type | Crimp |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Receptacle for Female Contacts |
| Fastening Type | Bayonet Lock | Mounting Style | In-Line |
| Insertion Angle | :- | Material - Body | :PBT (Polybutylene Terephthalate), PC (Polycarbonate) |
| Housing Material | Polycarbonate (PC), Polybutylene Terephthalate (PBT) | Termination Style | Crimp |
| 1st Contact Gender | :Socket | Number of Contacts | 10 |
| Number of Positions | 10 | Shell Size - Insert | :(Not Available) |
| Shell Material, Finish | Polycarbonate/Polybutylene Terephthalate (PBT) | 1st Connector Mounting Type | :Cable |
Product Info
| Note | Contacts Not Provided | Gender | :Plug |
| Series | 7000 | Product Type | Receptacles |
Environmental
| Ingress Protection | IP66/68/69K - Dust Tight, Water Resistant, Waterproof | ||
