2GK51-73
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 30 Days | Subcategory | Switch Toggle |
| Product Category | Toggle Switches | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | Standards | ULListed,CSACertified |
| Tariff No | 85365080 | ||
Electrical
| Circuit | DPST | Operation | OnNoneOff |
| Voltage Rating | 125V | Number of Poles | 2 |
| Switch Function | On-Off | Dielectric Strength | 1000V |
| Current Rating (Max) | 15@125VAC A | Current - Max/Contact | :15A |
| Voltage - Input (Min) | 250 V | Switch Function/Rating | ON None OFF |
| Connector - Voltage Input | :Quick Connect | Voltage - Rated AC (Phase to Ground/Neutral) | :250V |
Mechanical
| Weight | 0.032 | Packaging | Bulk |
| Termination | QCTabs | Contact Form | DPST |
| Actuator Type | Standard Round | Mounting Type | Panel Mount with Threads |
| Terminal Type | Quick Connect | Bushing Thread | 15/32-32 |
| Contact Finish | Nickel | Mounting Style | Panel |
| Actuator Length | 17.45mm | Contact Material | Silver |
| Termination Style | Quick Connect - 0.250" (6.3mm) | Actuator Style/Size | :Bat |
| Number of Positions | 2 | Bushing, Grommet Type | 15/32-32 |
| Mounting Hole Diameter | 12.7 mm | Switch Actuation Level | DPST |
| Contact Layout, Typical | :DPST | Panel Cutout Dimensions | Circular - 12.70mm Dia |
| 1st Connector Mounting Type | :- | ||
Product Info
| Type | Toggle | Series | G |
| Illumination | Non-Illuminated | Electrical Life | 50,000 Cycles |
| Industry Aliases | 2GK51-73 | Application Specifics | ForusageinlowvoltageDCapplications |
Environmental
| Seal Rating | Unsealed | Mechanical Life | 100000 Cycles |
| Operating Temperature | 0 to 85 °C | Operating Temperature - Junction | 85°C |
Documents & Media
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- Carling-TS-G-Series.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
