P-302H-CCT
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Jones Plugs & Sockets | Standard Package | 500 |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | RoHS Compliant | Standards | ULRecognizedFileNo:E170218(UL1977),E130965(UL1863),CSA-LR31996 |
| Approval Agency | CSA,UL | Material Flammability Rating | UL94V-0 |
Electrical
| Voltage Rating | 250V | Current Rating (Max) | 10A |
Mechanical
| Color | Black | Width | 0.691in.±0.016in. |
| Diameter | 0.375in. | Material | Thermoplastic |
| Packaging | Bulk | Termination | Solder Eyelet(s) |
| Mounting Type | Free Hanging (In-Line) | Angle of Throw | Straight |
| Connector Type | Plug, Jones | Contact Finish | Tin |
| Fastening Type | Push-Pull | Number of Rows | 1 |
| Contact Material | Brass | Housing Material | Thermoplastic |
| Length - Overall | 0.691" | Primary Material | Jones |
| Number of Contacts | 2 | Dielectric Material | Phenolic |
| Number of Positions | 2 | Material - Insulation | Phenol Formaldehyde (Phenolic) |
Product Info
| Type | CablePlug | Series | 300 |
| Features | Hood, Cable Clamp | Manufacturer | 300Series |
| Product Type | Plug Housings | For Use With/Related Products | Cabletopanel&cabletocableapplications |
Environmental
| Operating Temperature | 105°C | ||
Documents & Media
Online Document
Online Document
Sourcing & traceability
- Datasheet
- 300 Series, Plugs/Sockets
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
