S-2406H-CCT
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Jones Plugs & Sockets | Standard Package | 500 |
Compliance
| RoHS | RoHS Compliant | Standards | ULRecognized,CSACertified |
| Tariff No | 85366910 | Approval Agency | CSA,UL |
Electrical
| Voltage Rating | 250V | Current Rating (Max) | 15A |
Mechanical
| Color | Black | Weight | 0 |
| Diameter | 0.093in. | Material | Metal |
| Packaging | Bulk | Termination | Solder Eyelet(s) |
| Mounting Type | Free Hanging (In-Line) | Angle of Throw | Straight |
| Cable Diameter | 0.438" | Connector Type | Socket, Jones |
| Contact Finish | Tin | Fastening Type | Push-Pull |
| Number of Rows | 2 | Contact Material | Phosphor Bronze |
| Length - Overall | 1.5" | Primary Material | Jones |
| Pin Hole Diameter | 0.5" | 1st Contact Gender | :Socket |
| Number of Contacts | :6 | Contact Termination | :Solder |
| Dielectric Material | Phenolic | Number of Positions | 6 |
| Material - Insulation | Phenol Formaldehyde (Phenolic) | 1st Connector Mounting Type | :Cable |
Product Info
| Type | CableSocket | Gender | :Receptacle |
| Series | :2400 | Features | Hood, Cable Clamp |
| Manufacturer | 2400Series | For Use With/Related Products | Cable-to-cableandcable-to-panelapplications |
Environmental
| Operating Temperature | 105°C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 678856.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
