CS5345-CQZ
| Manufacturer | |
| Description | ADC Dual Delta-Sigma 192ksps 24-bit Serial 48-Pin LQFP Tray IC ADC 24BIT SRL 192KHZ 48-LQFP Audio A/D Converter ICs 105dB 24-Bit 192kHz Stereo Audio ADC |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio ADCs | Product Category | Audio A/D Converter ICs |
| Standard Package | Rail / Tube | Factory Pack Quantity | 250 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Interface | Serial | Input Type | Voltage |
| Resolution | 24 Bit | Data Interface | Serial |
| Input Polarity | Bipolar | Voltage Rating | +/- 0.0425 V, +/- 1.425 V |
| Data Rate (Max) | 192 KSPs | Voltage - Supply | 3.13 V ~ 5.25 V |
| Resolution (Bits) | 24 b | Sampling Frequency | 192 ksps |
| Number of ADCs / DACs | 2 | Voltage Supply Source | Analog and Digital |
| Power - Average Forward | 400 mW | Sampling Rate (Per Second) | 192k |
| S/N Ratio, ADCs / DACs (db) Typ | 105 dB | ||
Mechanical
| Height | 1.3 mm | Length | 7 mm |
| Packaging | Tray | Mounting Type | Surface Mount |
| Diameter - Bit | 24 b | Mounting Style | SMD/SMT |
| Package / Case | 48LQFP | Supplier Device Package | 48-LQFP (7x7) |
Product Info
| Type | ADC, Audio | Series | CS5345 |
| Architecture | Delta-Sigma | Manufacturer | Cirrus Logic |
| Number of A/D Converters | 6 | ||
Environmental
| Operating Temperature | -10°C ~ 70°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- CS5345_F4.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
