CS5346-CQZ
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio ADCs | Product Category | Audio A/D Converter ICs |
| Standard Package | Rail / Tube | Factory Pack Quantity | 250 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Noise | - 95 dB | Interface | Serial |
| Input Type | Voltage | Resolution | 24 Bit |
| Data Interface | Serial | Input Polarity | Bipolar |
| Voltage Rating | +/- 1.425 V | Data Rate (Max) | 192 KSPs |
| Current - Output | 41 mA | Current - Supply | 41 mA |
| Voltage - Supply | 3.3V, 5V | Resolution (Bits) | 24 b |
| Number of Channels | 1 | Sampling Frequency | 192 ksps |
| Number of ADCs / DACs | 2 | Voltage Supply Source | Analog and Digital |
| Power - Average Forward | 205 mW | Sampling Rate (Per Second) | 192k |
| S/N Ratio, ADCs / DACs (db) Typ | No | ||
Mechanical
| Height | 1.45 mm (Max) | Length | 7.1 mm (Max) |
| Packaging | Tube | Mounting Type | Surface Mount |
| Diameter - Bit | 24 b | Mounting Style | SMD/SMT |
| Package / Case | 48LQFP | Supplier Device Package | 48-LQFP (7x7) |
Product Info
| Type | ADC, Audio | Series | CS5346 |
| Architecture | Delta-Sigma | Manufacturer | Cirrus Logic |
| Number of A/D Converters | 6 | ||
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
