CS8421-CZZ
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio SRCs | Product Category | Audio DSPs |
| Standard Package | Rail / Tube | Factory Pack Quantity | 74 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Data Rate | 211kHz | Resolution | 32 bit |
| Voltage Rating | 2.38 V | Data Rate (Max) | 211kHz |
| Current - Output | 200 uA | Voltage - Supply | 3.3 V, 5 V |
| Voltage - Supply (Min) | 2.62 V | ||
Mechanical
| Width | 4.50mm | Height | 0.95mm |
| Length | 6.60mm | Packaging | Tube |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | 20 | Package / Case | 20TSSOP |
| Package Cooled | TSSOP | Package Quantity | TSSOP |
| Size / Dimension | 6.6 x 4.5 x 0.95mm | Number of Positions | 20 |
| Supplier Device Package | 20-TSSOP | ||
Product Info
| Type | Sample Rate Converter | Series | CS8421 |
| Function | Y | Applications | CD-R, DAT, DVD, MD, VTR |
| Manufacturer | Cirrus Logic | RF Family/Standard | CS8421 |
Environmental
| Operating Temperature | -10 to 70 °C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- CS8421_F6.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
