ATE2E-5M3-10-Z
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 100 | ||
Electrical
| Circuit | DPDT | Voltage Rating | 48V |
| Switch Function | On-Off-On | Voltage - Rated AC | 48V |
| Current Rating (Max) | 50mA (AC/DC) | ||
Mechanical
| Packaging | Bulk | Light Color | Non-Illuminated |
| Actuator Type | Standard Round | Mounting Type | Through Hole, Right Angle |
| Bushing Thread | Unthreaded | Actuator Length | 6.00mm |
| Termination Style | PC Pin | ||
Product Info
| Series | ATE | Features | Washable |
| Circuit Type | DPDT | Illumination | Non-Illuminated |
| Electrical Life | 50,000 Cycles | Output Configuration | Through Hole, Right Angle |
Environmental
| Operating Temperature | -20°C ~ 85°C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- ATE Series
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
