SFA66S4K288B
| Manufacturer | |
| Description | Cap Film 4uF 660VAC PP 10% (54.864 X 33.274 X 73.152mm) Bracket Mount Metal Can 70°C CAP FILM 4UF 660VAC QC TERM |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 13 | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | EU RoHS | Not Compliant |
Electrical
| Voltage | 660VAC | Tolerance | 10% |
| Capacitance | 4uF | Voltage Rating | 660V |
Mechanical
| Depth | 33.274 | Height | 73.152 |
| Packaging | Bulk | Termination | Quick Connect, Disconnect |
| Construction | Metal Can | Lead Spacing | 0.810" (20.57mm) |
| Mounting Type | Bracket Mount | Package / Case | Radial, Can - QC Terminals |
| Length - Overall | 54.864 | Size / Dimension | 2.160" L x 1.310" W (54.86mm x 33.27mm), Lip |
| Termination Style | Dual Tab Connector | Dielectric Material | PP |
| Height - Seated (Max) | 3.000" (76.20mm) | ||
Product Info
| Type | Motor Run and Power Supply | Applications | Power Factor Correction (PFC) |
Environmental
| Operating Temperature | -40°C ~ 70°C | ||
Documents & Media
PDF Document
