Business
| Other Names | 306-1155 | Product Category | Reed Relays |
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | In Transition | ||
Electrical
| Coil Type | Non Latching | Coil Current | 31.3mA |
| Release Time | 0.03ms | Power - Output | 3 W |
| Coil Resistance | 176 Ohms | Voltage - Supply | 4 V |
| Switching Voltage | 125VAC, 125VDC - Max | Vgs(th) (Max) @ Id | 0.4 VDC |
| Current - Switching | 0.25 Amps | Current Rating (Max) | 0.25 A |
| Vce(on) (Max) @ Vge, Ic | 3.8 VDC | Contact Rating (Current) | 250mA |
Mechanical
| Packaging | Reel | Contact Form | 4PST (4 Form A) |
| Mounting Type | Surface Mount | Termination Style | BGA |
| Contact Layout, Typical | 4A 4PST-NO | ||
Product Info
| Form | SMD/SMT | Type | Ball Grid Array Relays |
| Relay Type | RF | Card Standard | Reed Relay |
Environmental
| Operate Time | 0.1ms | Operating Temperature | -20°C ~ 85°C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- B40 4-Channel RF Relays
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
