EFB0405HHA-F00
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 640 | ||
Electrical
| Noise | 33 dB(A) | Power (Watts) | 0.95W |
| Voltage Range | 4.5 ~ 5.5VDC | Voltage Rating | 5VDC |
| Current Rating (Max) | 0.190A | ||
Mechanical
| RPM | 7000 RPM | Weight | 0.032 lb (14.51g) |
| Air Flow | 8.1 CFM (0.230m³/min) | Fan Type | Tubeaxial |
| Termination | 3 Wire Leads | Bearing Type | Ball |
| Static Pressure | 0.174 in H2O (43.3 Pa) | Material - Blade | Plastic |
| Material - Frame | Plastic | Size / Dimension | Square - 40mm L x 40mm H x 10mm W |
Product Info
| Features | Speed Sensor (Tach) | ||
Environmental
| Rated Life | 70000 hrs @ 40°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
