8412NGH

Business

Noise	37 dB(A)	Speed	Counter Clockwise
Frequency	Not Required Hz	Input Range	8V to 13.2V
Noise Figure	37 dB	Power (Watts)	2.20W
Power - Rated	2.2 W	Voltage Range	8 ~ 13.2VDC
Voltage Rating	12VDC	Voltage - Supply	12 V
Power Supply Type	:Wire Leaded	Voltage - Input (Min)	:7V
Power - Average Forward	:2.8W	Voltage - Continuous Operating (Max) (MCOV)	:15V

Depth	80 mm	Width	:80mm
Height	25.4 mm	Weight	0.21 lb (95.25g)
Air Flow	46.5 CFM (1.32m³/min)	Diameter	Not Required mm
Fan Type	Tubeaxial	Flow (CFM)	:79m³/h
Flow (SCFM)	:46.5cu.ft/min	Termination	2 Wire Leads
Bearing Type	Sintec	Height (Max)	:80mm
Mounting Style	Flange	Housing Material	Polybutylene Terephthalate (PBT)
Length - Overall	80 mm	Material - Blade	Polyamide (PA), Fiberglass Reinforced
Material - Frame	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	Size / Dimension	Square - 80mm L x 80mm H x 25.4mm W
Length - Lead Wire	:310mm	Panel Cutout Shape	:77mm
Mounting Hole Diameter	:4.5mm	Mounting Panel Thickness	:71.5mm
