B82723A2102N001
| Manufacturer | |
| Description | Common Mode Chokes Dual 27mH 10kHz 1A 750mOhm DCR Thru-Hole Box CHOKE, RING CORE, DOUBLE, 27MH, 1A EPCOS B82721A 系列 27 mH ±30% 铁氧体 电流补偿扼流圈, 1A Idc, 750mΩ Rdc |
| Category |
对参数有疑问？问 AI 助手
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85045095 |
| Rad Hardened | No | Military Standard | Not Required |
Electrical
| Core Type | :Power Line Choke | Impedance | Not Required ohm |
| Tolerance | 30% | Inductance | 27000 uH |
| Range deg/s | :EPCOS - B82723A Series | Test Frequency | 0.01 MHz |
| Inductance Range | :± 30% | Current Rating - DC | :1A |
| Current Rating (Max) | :1A | DC Resistance (DCR) (Max) | :0.75ohm |
| Current - DC Forward (If) (Max) | 1000 mA | ||
Mechanical
| Depth | 27 mm | Height | 16.8 mm |
| Weight | 0.026 | Diameter | Not Required mm |
| Packaging | Box | Lead Style | Pin |
| Lead Spacing | 25 mm | Core Material | Ferrite |
| Number of Pins | :4 | Package / Case | :Through Hole |
| Length - Overall | 28 mm | ||
Product Info
| Type | Power Line Choke | Failure Rate | Not Required |
