XRP7704ILB-F
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 1016-1345 | Product Category | Switching Controllers |
| Standard Package | 490 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423990 | Rad Hardened | No |
Electrical
| PWM Type | Controller | Duty Cycle | 85% |
| Cuk Converter | No | Buck Converter | Yes |
| Isolated Power | No | Voltage Rating | 5.1 V |
| Boost Converter | No | Frequency - Max | 1.5MHz |
| Current - Output | :5A | Current - Supply | 50 mA |
| Voltage - Supply | 6.5 V ~ 20 V | Doubler Converter | No |
| Flyback Converter | No | Number of Outputs | 4 |
| Divider/Multiplier | No | Inverting Converter | No |
| Frequency - Switching | 1500 kHz | Voltage - Input (Min) | :20V |
| Voltage - Output (Max) | :5.1V | Number of Outputs and Type | 4 |
| Voltage - Output (Min/Fixed) | :0.9V | ||
Mechanical
| Width | 6mm | Height | 0.73mm |
| Length | 6mm | Weight | 0.00022 |
| Packaging | Bulk | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :40 | Package / Case | 40-WFQFN Exposed Pad |
| Package Cooled | TQFN | Material Finish | :MSL 2 - 1 year |
| Length - Overall | 6 | Package Quantity | TQFN EP |
| Size / Dimension | 6 x 6 x 0.73mm | Number of Positions | 40 |
| Shell Size - Insert | 0.73 | ||
Product Info
| Type | DPWM DC to DC Controller/Step Down | Controller Type | DC to DC Converter and Switching Regulator Chip |
| Printed Circuit Board | 40 | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | Operating Temperature - Junction | 125C |
Documents & Media
Similar Parts
Sourcing & traceability
- Datasheet
- XRP7704
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
