Business
| Standard Package | 1 | ||
Compliance
| RoHS | Compliant | ||
Electrical
| Voltage | 120V | Conductor Strand | 7/32 |
| Number of Conductors | 2 | ||
Mechanical
| Color | Clear | Length | 1000' (304.8m) |
| Cable Type | Speaker | Wire Gauge | 24 AWG |
| Shield Type | NO | Conductor Type | STRANDED CONDUCTOR |
| Conductor Material | Copper, Bare; Copper, Tinned | Insulation Material | PVC-POLYVINYL CHLORIDE |
| Wire Gauge or Range - mm2 | 24 AWG (AMERICAN WIRE GAUGE) | Jacket (Insulation) Diameter | 0.117" (2.97mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | Jacket (Insulation) Thickness | 0.016" (0.41mm) |
Product Info
| Usage | Audio-Video, Home | ||
Environmental
| Ratings | NOT LISTED BY UL UNDER NEC | Fire Rating | GENERAL PURPOSE |
Documents & Media
Online Document
Sourcing & traceability
- Datasheet
- Audio/Video & Home Entertainment
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
