59170-1-S-00-A
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Supplier Unconfirmed |
Electrical
| Circuit | SPST-NO | Sensitivity | 10~15 AT |
| Release Time | 0.5 | Power - Rated | 10 |
| Voltage Rating | 200 | Current - Carry | 0.8 Amps |
| Current - Output | 500 mA | Sensing Distance | 7.5 mm |
| Voltage - Supply | 200 V | Switching Voltage | 200V |
| Contact Resistance | 100 | Current - Switching | 500mA |
| Current Rating (Max) | 0.5 | Switch Function/Rating | N.O. |
| Voltage - Switching DC | 200 VDC | Power - Average Forward | 10W |
Mechanical
| Packaging | Bulk | Termination | Axial (2 Leads) |
| Contact Form | Form A | Mounting Type | Through Hole |
| Terminal Type | PC Pins | Mounting Style | Screw |
| Length - Overall | 40.39 | Material - Magnet | Specified, Not Included |
| Termination Style | Axial (2 Leads) | Contact Layout, Typical | 1A SPST-NO |
Product Info
| Type | Molded Body | Card Standard | Reed Sensor |
| Sensing Method | Magnetic | Other Specifications | .295" (7.5mm) |
Environmental
| Must Operate | 10 ~ 15AT | Operating Temperature | + 105 C |
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- Ampere*turn vs. mT & Gauss App Note
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
