09330102602

Business

Part # Aliases	010 09 09-33-010-2602 2602 33	Product Category	Heavy Duty Power Connectors
Standard Package	1	Factory Pack Quantity	10

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Tariff No	85369010	Material Flammability Rating	UL94 V-0

Voltage Rating	600V	Current Rating (Max)	16A
Voltage - Input (Min)	500V	Connector - Voltage Input	w/o terminals

Size	10B	Color	Gray
Depth	33.3	Height	34
Weight	0.045	Packaging	Bulk
Weight (g):	48.00000	Contact Type	Han®
Mounting Type	Straight	Connector Type	Insert without Contacts
Number of Rows	2	Package / Case	size 10B
Insert Material	:Signal	Insertion Force	Male
Housing Material	Polycarbonate (PC)	Length - Overall	64
Size / Dimension	10B	Termination Style	Crimp
Number of Contacts	10	Number of Positions	10+Ground
Shell Size - Insert	:10B	Wire Gauge or Range - AWG	20-12
1st Connector Mounting Feature	10+PE

Type	Housing	Gender	M
Series	Han-E	CAD Drawing	3D CAD Model
Product Type	Housings	Adapter Series	Han E
Number of Units	1	For Use With/Related Products	:Female crimp contacts, Han 10E Housings and Hoods
