09360083101

点击放大查看

09360083101

Category

Connector SolutionsHeavy Duty ConnectorsHeavy Duty Connectors

对参数有疑问？问 AI 助手

Business

Part # Aliases	008 09 09-36-008-3101 3101 36	Product Category	Heavy Duty Power Connectors
Standard Package	1	Factory Pack Quantity	10

Compliance

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Material Flammability Rating	UL94 HB

Electrical

Voltage - Test	4kV	Voltage Rating	50V
Current Rating (Max)	10A	Voltage - Input (Min)	50V
Connector - Voltage Input	w/o terminals

Mechanical

Size	3A	Color	Gray
Depth	33.5	Height	21
Weight	8.15 g	Packaging	Bulk
Orientation	直	Weight (g):	7.60000
Contact Type	Han® D	Mounting Type	Straight
Connector Type	Insert without Contacts	Package / Case	size 3A
Insertion Force	Female	Housing Material	Polyamide (PA), Nylon
Length - Overall	21	Package Quantity	10
Size / Dimension	3A	Termination Style	Crimp
Number of Contacts	8	Number of Positions	8
Material - Insulation	polycarbonate

Product Info

Spg	10	Type	Housing
Gender	F	Series	Han D
CAD Drawing	3D CAD Model	Product Type	Inserts
Adapter Series	Han D	Number of Units	1

Environmental

Operating Temperature

-40°C ~ 125°C
