09380062711

Category

Connector SolutionsHeavy Duty ConnectorsHeavy Duty Connectors

对参数有疑问？问 AI 助手

Business

Part # Aliases	006 09 09-38-006-2711 2711 38	Product Category	Heavy Duty Power Connectors
Standard Package	1	Factory Pack Quantity	10

Compliance

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Material Flammability Rating	UL94 V-0

Electrical

Voltage Rating

830 V

Current Rating (Max)

80 A

Mechanical

Size	16B	Color	Gray
Depth	76	Height	55.6
Weight	0.12 kg	Packaging	Bulk
Weight (g):	116.00000	Connector Type	Insert
Contact Finish	Silver	Package / Case	size 16B
Insertion Force	Female	Contact Material	Copper Alloy
Housing Material	Polycarbonate (PC)	Length - Overall	120
Package Quantity	1	Size / Dimension	16B
Termination Style	Screw	Number of Contacts	4
Number of Positions	4+0+Ground	Wire Gauge or Range - AWG	16-6
Wire Gauge or Range - mm2	16mm2

Product Info

Spg	1	Type	Hood
Gender	Female	Series	Han Com
CAD Drawing	3D CAD Model	Product Type	Housings
Accessory Type	Hood	Adapter Series	Han Com
Number of Units	1

Environmental

Operating Temperature

-40°C ~ 125°C
