M22-2010405
| Manufacturer | |
| Description | HARWIN M22-20 Series 2mm Pitch 4 Way 1 Row Straight PCB Header, Solder Termination, 1A HEADER, VERTICAL, 1ROW, 4WAY HARWIN M22 系列 2mm节距 4路 (1排) 直 引脚管座, 焊接端接, 1A , 通孔 |
| Category |
对参数有疑问？问 AI 助手
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Material Flammability Rating | :UL94V-0 | ||
Electrical
| Range deg/s | :HARWIN - M22 Series | Voltage Rating | :250V |
| Voltage - Working | :250V | Current Rating (Max) | 1A |
| Current - Max/Contact | :2A | Insulation Resistance | :10000Mohm |
Mechanical
| Pitch | 2mm | Weight | 0.009 |
| Termination | Solder | Lead Spacing | :2mm |
| Mounting Type | Straight | Contact Finish | :Gold |
| Number of Rows | 1 | Package / Case | :Glass Filled Thermoplastic |
| Contact Material | Phosphor Bronze | Number of Contacts | 4 |
| Contact Termination | :Through Hole Vertical | ||
Product Info
| Type | Unshrouded Header | Gender | :Header |
| Series | M22-20 | CAD Drawing | 3D CAD Model |
Environmental
| Operating Temperature | :85°C | ||
Documents & Media
PDF Document
Similar Parts
M22-7130442
