Business
| Product Category | Headers & Wire Housings | Factory Pack Quantity | 2500 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85369010 | ||
Electrical
| Voltage Rating | 250 V | Contact Resistance | 25mΩ |
| Current Rating (Max) | 3 A | Insulation Resistance | 1000 MOhms |
Mechanical
| Depth | 2.3mm | Pitch | 2.54mm |
| Width | 5mm | Length | 6.3mm |
| Weight | 0.007 | Orientation | Straight |
| Contact Finish | Gold | Number of Rows | 1 |
| Package / Case | :Glass Filled Polyester UL94V-0 | Contact Material | Phosphor Bronze |
| Housing Material | Polyester | Color - Connectors | Grey |
| Number of Contacts | 2 | Number of Positions | :2 |
Product Info
| Type | Jumper | Gender | Female |
| Series | M75 | Product Type | Shunts |
| Accessory Type | :Jumper | For Use With/Related Products | :M20 Connectors |
Environmental
| Mating Cycles | :300 | Operating Temperature | - 40 C to + 85 C |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- M7565-M7571.PDF
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
