19N502
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 74 Days | Subcategory | Switch Snap Action |
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85365007 |
| Approval Agency | :BEAB, VDE | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage - Core | :250V | Differential Travel | :0.2mm |
| Current - Modulation | :5A | Current - Max/Contact | :5A |
| Switch Function/Rating | :On-(On) | Contact Rating (Current) | :5A |
| Connector - Voltage Input | :Solder | Voltage - Supply (Vcc/Vdd) | :28V |
| Voltage - Rated AC (Phase to Ground/Neutral) | :250V | ||
Mechanical
| Depth | :6.35mm | Width | :19.9mm |
| Length | :11.1mm | Weight | 0.002 |
| Pretravel | :1.2mm | Actuator Type | :Plunger |
| Release Force | :0.27N | Terminal Type | :Solder |
| Package / Case | :Nylon 4.6 (Polyamide 4.6) | Operating Force | :2N |
| Actuator Style/Size | :Plunger | Number of Positions | :100000 |
| Switch Actuation Level | :Snap Action | Contact Layout, Typical | :SPDT |
| Mounting Panel Thickness | :9.53mm | ||
Product Info
| Series | :19N | ||
Environmental
| NEMA Frame Size | :IP67 | Switching Cycles | :10000000 |
| Operating Temperature | :125°C | ||
Documents & Media
PDF Document
PDF Document
Similar Parts
Sourcing & traceability
- Datasheet
- Series_19.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
