5M160ZE64C5N
| Category |
对参数有疑问？问 AI 助手
Business
| Product | MAX V | Standard Package | 250 |
| Factory Pack Quantity | 250 | Standard Package Name | QFP |
Compliance
| RoHS | Contains lead / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423190 | ||
Electrical
| Frequency | :118.3MHz | Delay Time | 7.5 ns |
| Memory Size | 8192 bit | Memory Type | Flash |
| Number of I/O | 54 | Voltage Rating | 1.71 |
| Circuit Pattern | :FLASH | Frequency - Max | 152 MHz |
| Current - Supply | 25 uA | Voltage - Supply | 1.8 V |
| Propagation Delay | :7.5ns | Program Memory Type | Flash |
| Delay Time tpd(1) Max | 7.5ns | Voltage - Supply (Min) | 1.89 |
| Delay Time - Propagation | :4.4ns | Voltage Supply - Internal | 1.71 V ~ 1.89 V |
| Propagation Delay tpLH / tpHL (Max) | 14|8.5 | Common Mode Transient Immunity (Min) | Commercial |
Mechanical
| Width | 7 | Weight | 0.35 |
| Packaging | Tray | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :64 | Package / Case | 64-TQFP Exposed Pad |
| Material Finish | :MSL 3 - 168 hours | Length - Overall | 7 |
| Package Quantity | EQFP EP | Number of Positions | 64 |
| Shell Size - Insert | 1 | Supplier Device Package | 64-EQFP (7x7) |
Product Info
| Series | MAX V | Function | :CPLD |
| Programmable Type | In System Programmable | RF Family/Standard | MAX V |
| User Configuration | 8192 bit | Number of LABs/CLBs | 16 |
| DigiKey Programmable | Yes | Number of Macrocells | 128 |
| In System Programming | Yes | Printed Circuit Board | 64 |
| Number of Inputs and Type | 54 | Number of Logic Elements/Cells | 160 |
| Number of Logic Elements/Blocks | 8 | ||
Environmental
| Operating Temperature | 0°C ~ 85°C | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- MAX V Datasheet
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
