KPSE07E14-15SDX
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :MIL-C-26482 | ||
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A, 13A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Crimp |
| Weight (g): | 38.90900 | Mounting Type | Panel Mount, Bulkhead - Front Side Nut |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Insertion Angle | :14-15 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Socket | Number of Contacts | :15 |
| Contact Termination | :Crimp | Number of Positions | 15 |
| Shell Size - Insert | 14-15 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish Thickness | 50µin (1.27µm) | 1st Connector Mounting Type | :Panel |
Product Info
| Gender | :Socket | Series | :KPSE |
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
Documents & Media
Online Document
PDF Document
