点击放大查看
KPT02E16-26PF80
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :VG95328 | ||
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Crimp |
| Mounting Type | Panel Mount, Flange | Connector Type | Receptacle, Male Pins |
| Contact Finish | Gold | Fastening Type | Bayonet Lock |
| Insertion Angle | :16-26 | Material - Body | :Aluminium |
| Contact Material | :Copper | 1st Contact Gender | :Pin |
| Number of Contacts | :26 | Contact Termination | :Solder |
| Number of Positions | 26 | Shell Size - Insert | 16-26 |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | Contact Finish Thickness | 50µin (1.27µm) |
| 1st Connector Mounting Type | :Panel | ||
Product Info
| Gender | :Plug | Series | :KPT |
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
Documents & Media
Online Document
PDF Document
