KPT04A12-10PW
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| SVHC | :No SVHC (20-Jun-2013) | Tariff No | 85369010 |
| Approval Agency | :VG95328 | ||
Electrical
| Voltage Rating | 600VAC, 850VDC | Current Rating (Max) | 7.5A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | W | Termination | Solder Cup |
| Weight (g): | 13.56100 | Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle, Male Pins | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Insertion Angle | :12-10 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Pin | Number of Contacts | :10 |
| Contact Termination | :Solder | Number of Positions | 10 |
| Shell Size - Insert | 12-10 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish Thickness | 50µin (1.27µm) | 1st Connector Mounting Type | :Cable |
Product Info
| Gender | :Plug | Series | :KPT |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
Online Document
Sourcing & traceability
- Datasheet
- KPT/KPSE Connectors Catalog
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
