KPT07A14-5SY
| Manufacturer | |
| Description | Conn MIL-C-26482 Circular SKT 5 POS Solder ST Jam Nut 5 Terminal 1 Port CONN RCPT 5POS JAM NUT SKT CONNECTOR, CIRCULAR, SIZE 14, 5WAY |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | KPT07A145SY | Standard Package | Bulk |
Compliance
| RoHS | Contains lead / RoHS non-compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Not Compliant | Tariff No | 85369010 |
| Approval Agency | :VG95328 | ||
Electrical
| Voltage Rating | 1000VAC, 1400VDC | Current Rating (Max) | 13A |
Mechanical
| Depth | 35 | Height | 35 |
| Weight | 0.001 | Diameter | 39 |
| Packaging | Bulk | Cable Exit | No |
| Orientation | Y | Termination | Solder |
| Weight (g): | 26.67600 | Contact Type | 5Signal |
| Mounting Type | Jam Nut | Shell Plating | Conductive Olive Drab Chromate Ov... |
| Connector Type | Receptacle, Female Sockets | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Package / Case | :Jam Nut Receptacle |
| Insertion Angle | :14-5 | Material - Body | :Aluminium |
| Contact Material | Copper Alloy | Length - Overall | 25.6 |
| 1st Contact Gender | SKT | Number of Contacts | 5 |
| Contact Termination | :Solder | Number of Positions | 5 |
| Shell Size - Insert | 14-5 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Finish Thickness | 50µin (1.27µm) | 1st Connector Mounting Type | :Panel |
| Shell Size - Insert (Convert To) | 14-5 | ||
Product Info
| Type | MIL-C-26482 Circular | Gender | RCP |
| Series | :KPT | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
